Elevator

Model

Diameter of pipe (in)

Rated Capacity

Drill pipe

Casing

Tubing

DD-100

2 3/8~5 1/2

4 1/2~5 1/2

2 3/8~4 1/2

150

DD-250

2 3/8~5 1/2

4 1/2~5 1/2

2 3/8~4 1/2

250

DD-350

2 3/8~5 1/2

4 1/2~5 1/2

2 3/8~4 1/2

350

Model

Diameter of pipe (in)

Rated Capacity

Remark

DDZ-100

2 3/8~5

100

MG

DDZ-150

2 3/8~5 1/2

150

RG

DDZ-250

2 3/8~5 1/2

250

MGG

DDZ-350

3 1/2~5 7/8

350

GG

DDZ-350TD

3 1/2~5 7/8

350

For top drive

DDZ-500

3 1/2~6 5/8

500

HGG

DDZ-500TD

3 1/2~6 5/8

500

For top drive

DDZ-750

4~6 5/8

750

------

Model

Diameter of pipe (in)

Rated Capacity

CD-100

2 3/8~5 1/2

100

CD-150

2 3/8~14

150

CD-200

2 3/8~14

200

CD-250

2 3/8~20

250

CD-350

4 1/2~20

350

CD-500

4 1/2~14

500

CD-750

4 1/2~9 7/8

750

Model

Diameter of pipe (in)

Rated Capacity

Drill Collar

Tubing

Casing

NU

EU

TA-35

2 7/8~3 1/8

1.05~2 7/8

1.05~2 7/8

------

35

TA-65

2 7/8~3 1/8

1.66~2 7/8

1.66~2 7/8

------

65

TA-100

3 1/8~5 1/4

2 3/8~5

2 3/8~4 1/2

------

100

TA-125

3 1/8~5 1/4

2 3/8~5

2 3/8~4 1/2

------

125

TA-150

4 1/8~11 1/4

------

------

------

150

Model

Diameter of pipe (in)

Rated Capacity

SLX-65

3 1/2~14 1/4

65

SLX-100

2 3/8~5 3/4

100

SLX-150

5 1/2~13 5/8

150

SLX-250

5 1/2~30

250

SLX-350

4 1/2~14

350

Model

Diameter of pipe

Rated Capacity

(mm/in)

KN

Short rons

HYT

60.3~88.9(2 3/8~3 1/2)

1350

150

YT

33.4~88.9(1.315~3 1/2)

675

75

MYT

33.4~73(1.315~2 7/8)

360

40

LYT

26.7~52.4(1.05~1 1/16)

180

20

HYC

88.9~139.7(3 1/2~7 5/8)

1800

200

MYC

88.9~117.8(3 1/2~7)

1125

125

YC

88.9~117.8(3 1/2~7)

675

75

Diameter of pipe

Rated Capacity

in

mm

45

2 3/8~2 7/8

60.3~73.03

3 1/2~4 3/4

88.9~120.7

5~5 3/4

127~146.1

6~7 3/4

152.4~193.7

8 5/8~10 3/4

219.1~273.1

11 3/4~13 3/8

298.5~339.7

             13 5/8~14

346.1~355.6

16~20

406.4~508.0

21 1/2~24 1/2

546.1~622.3

60

26~28

660.4~711.2

30~36

762.0~914.4
